Troubleshooting by Remote Controller SiBE37-701_B
249 Troubleshooting
Service Menu Item 2 Remarks
1.Model Name Display 1.Unit No. Select the Unit No. you want to check.
2.Indoor unit
3.Outdoor unit
2.Operating Hours
Display
1.Unit No. Select the Unit No. you want to check.
2.Indoor unit operating
time
All of these are displayed in hours.
3.Indoor fan operation
4.Indoor unit energized
time
5.Outdoor operating
time
6.Outdoor fan 1
operation
7.Outdoor fan 2
operation
8.Outdoor comp. 1
operation
9.Outdoor comp. 2
operation
3.Indoor Status Display
1/2
1.Unit No. Select the Unit No. you want to check.
2.FAN Tap, speed (rpm)
3. FLAP Swing, fixed
4.Speed Fan speed (rpm)
5.EV Degree that electronic expansion valve is open
(pls)
6. MP Drain pump ON/OFF
7. 52H Electric heater ON/OFF
8.Hu Humidifier ON/OFF
9.Anti-freezing Anti-freezing control ON/OFF
3.Indoor Status Display
2/2
1.Unit No. Select the Unit No. you want to check.
SkyAir VRV
2.Th1 Suction air thermistor Suction air thermistor
3.Th2 Heat exchanger
thermistor
Heat exchanger liquid
pipe thermistor
4.Th3 — Heat exchanger gas
pipe thermistor
5. Th4 Discharge air
thermistor
Discharge air
thermistor
6. Th5 — —
7. Th6 — —
4.Outdoor Status
Display
1.Unit No. Select the Unit No. you want to check.
2. FAN Tap 1 Fan tap
3.COMP Compressor power supply frequency (Hz)
4.EV1 Degree that electronic expansion valve is open
(pls)
5.SV1 Solenoid valve ON/OFF
SkyAir VRV
6.Th1 Outdoor air thermistor —
7.Th2 Heat exchanger
thermistor
—
8.Th3 Discharge pipe
thermistor
—
5.Forced Defrost
(SkyAir only)
1.Forced defrost ON Enables the forced defrost operation.
2.Forced defrost OFF Disables the forced defrost operation.
