ioLogik W5300 Click&Go Logic
4-28
DO
DO refers to the action of controlling the local digital output channels that react to the IF conditions. Select the
THEN/ELSE action to DO and click on the property button ( ) to enter the DO Settings window.
NOTE
A Relay output channel is also referred to as a DO channel in the THEN/ELSE action fields.
Pulse Output
Pulse Output starts or stops a pulse. It is usually used to create the flash for an alarm light. Select the
THEN/ELSE action to Pulse Output and click on the property button ( ) to enter the Pulse Output Settings
window.
