ioLogik W5300 Modbus/TCP Address Mapping
C-28
Reference Address Data Type Description
40076 0x004B 1 word CH3 DO Mode 0: DO
1: Pulse
40077 0x004C 1 word CH4 DO Mode 0: DO
1: Pulse
40078 0x004D 1 word CH5 DO Mode 0: DO
1: Pulse
40079 0x004E 1 word CH6 DO Mode 0: DO
1: Pulse
40080 0x004F 1 word CH7 DO Mode 0: DO
1: Pulse
40081 0x0050 1 word CH8 DO Mode 0: DO (DIO)
1: Pulse
40082 0x0051 1 word CH9 DO Mode 0: DO (DIO)
1: Pulse
40083 0x0052 1 word CH10 DO Mode 0: DO (DIO)
1: Pulse
40084 0x0053 1 word CH11 DO Mode 0: DO (DIO)
1: Pulse
40085 0x0054 1 word CH0 DI Count Filter
40086 0x0055 1 word CH1 DI Count Filter
40087 0x0056 1 word CH2 DI Count Filter
40088 0x0057 1 word CH3 DI Count Filter
40089 0x0058 1 word CH4 DI Count Filter
40090 0x0059 1 word CH5 DI Count Filter
40091 0x005A 1 word CH6 DI Count Filter
40092 0x005B 1 word CH7 DI Count Filter
40093 0x005C 1 word CH8 DI Count Filter (DIO)
40094 0x005D 1 word CH9 DI Count Filter (DIO)
40095 0x005E 1 word CH10 DI Count Filter (DIO)
40096 0x005F 1 word CH11 DI Count Filter (DIO)
40097 0x0060 1 word CH0 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40098 0x0061 1 word CH1 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40099 0x0062 1 word CH2 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40100 0x0063 1 word CH3 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40101 0x0064 1 word CH4 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
