ioLogik W5300 Modbus/TCP Address Mapping
C-20
Reference Address Data Type Description
00055 0x0036 1 bit CH6 DO PowerOn Pulse Operate Status 0: Off 1: On
00056 0x0037 1 bit CH7 DO PowerOn Pulse Operate Status 0: Off 1: On
00057 0x0038 1 bit CH8 DO PowerOn Pulse Operate Status 0: Off 1: On (DIO)
00058 0x0039 1 bit CH9 DO PowerOn Pulse Operate Status 0: Off 1: On (DIO)
00059 0x003A 1 bit CH10 DO PowerOn Pulse Operate Status 0: Off 1: On (DIO)
00060 0x003B 1 bit CH11 DO PowerOn Pulse Operate Status 0: Off 1: On (DIO)
00061 0x003C 1 bit CH0 DO Safe Pulse Operate Status 0: Off 1: On
00062 0x003D 1 bit CH1 DO Safe Pulse Operate Status 0: Off 1: On
00063 0x003E 1 bit CH2 DO Safe Pulse Operate Status 0: Off 1: On
00064 0x003F 1 bit CH3 DO Safe Pulse Operate Status 0: Off 1: On
00065 0x0040 1 bit CH4 DO Safe Pulse Operate Status 0: Off 1: On
00066 0x0041 1 bit CH5 DO Safe Pulse Operate Status 0: Off 1: On
00067 0x0042 1 bit CH6 DO Safe Pulse Operate Status 0: Off 1: On
00068 0x0043 1 bit CH7 DO Safe Pulse Operate Status 0: Off 1: On
00069 0x0044 1 bit CH8 DO Safe Pulse Operate Status 0: Off 1: On (DIO)
00070 0x0045 1 bit CH9 DO Safe Pulse Operate Status 0: Off 1: On (DIO)
00071 0x0046 1 bit CH10 DO Safe Pulse Operate Status 0: Off 1: On (DIO)
00072 0x0047 1 bit CH11 DO Safe Pulse Operate Status 0: Off 1: On (DIO)
00073 0x0048 1 bit CH0 DI Counter Status 0: Off 1: On
00074 0x0049 1 bit CH1 DI Counter Status 0: Off 1: On
00075 0x004A 1 bit CH2 DI Counter Status 0: Off 1: On
00076 0x004B 1 bit CH3 DI Counter Status 0: Off 1: On
00077 0x004C 1 bit CH4 DI Counter Status 0: Off 1: On
00078 0x004D 1 bit CH5 DI Counter Status 0: Off 1: On
00079 0x004E 1 bit CH6 DI Counter Status 0: Off 1: On
00080 0x004F 1 bit CH7 DI Counter Status 0: Off 1: On
00081 0x0050 1 bit CH8 DI Counter Status 0: Off 1: On (DIO)
00082 0x0051 1 bit CH9 DI Counter Status 0: Off 1: On (DIO)
00083 0x0052 1 bit CH10 DI Counter Status 0: Off 1: On (DIO)
00084 0x0053 1 bit CH11 DI Counter Status 0: Off 1: On (DIO)
00085 0x0054 1 bit CH0 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00086 0x0055 1 bit CH1 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00087 0x0056 1 bit CH2 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00088 0x0057 1 bit CH3 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00089 0x0058 1 bit CH4 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00090 0x0059 1 bit CH5 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00091 0x005A 1 bit CH6 DI Clear Count Value read aways :0
Write: 1 : Clear counter value
0 : return Illegal Data Value
