ioLogik W5300 Modbus/TCP Address Mapping
C-7
3xxxx Read-only Registers (supports function 4)
Reference Address Data Type Description
30001 0x0000 word CH0 DI Counter Value Hi- Word
30002 0x0001 word CH0 DI Counter Value Lo- Word
30003 0x0002 word CH1 DI Counter Value Hi- Word
30004 0x0003 word CH1 DI Counter Value Lo- Word
30005 0x0004 word CH2 DI Counter Value Hi- Word
30006 0x0005 word CH2 DI Counter Value Lo- Word
30007 0x0006 word CH3 DI Counter Value Hi- Word
30008 0x0007 word CH3 DI Counter Value Lo- Word
30009 0x0008 word CH4 DI Counter Value Hi- Word
30010 0x0009 word CH4 DI Counter Value Lo- Word
30011 0x000A word CH5 DI Counter Value Hi- Word
30012 0x000B word CH5 DI Counter Value Lo- Word
30013 0x000C word CH6 DI Counter Value Hi- Word
30014 0x000D word CH6 DI Counter Value Lo- Word
30015 0x000E word CH7 DI Counter Value Hi- Word
30016 0x000F word CH7 DI Counter Value Lo- Word
30017 0x0010 word CH8 DO Totoal Relay Count Value Hi-Byte (Relay)
30018 0x0011 word CH8 DO Totoal Relay Count Value Lo-Byte (Relay)
30019 0x0012 word CH9 DO Totoal Relay Count Value Hi-Byte (Relay)
30020 0x0013 word CH9 DO Totoal Relay Count Value Lo-Byte (Relay)
30025 0x0018 word CH0 Read AI Value
30026 0x0019 word CH1 Read AI Value
30027 0x001A word CH2 Read AI Value
30028 0x001B word CH3 Read AI Value
30033 0x001C word CH0 Read AI Min Value
30034 0x001D word CH1 Read AI Min Value
30035 0x001E word CH2 Read AI Min Value
30036 0x001F word CH3 Read AI Min Value
30037 0x0020 word CH0 Read AI Max Value
30038 0x0021 word CH1 Read AI Max Value
30039 0x0022 word CH2 Read AI Max Value
30040 0x0023 word CH3 Read AI Max Value
30041 0x0024 word CH0 Relay Totoal Relay Count Value (Relay)
30042 0x0025 word CH1 Relay Totoal Relay Count Value (Relay)
30043 0x0026 word CH0 Relay Last Reset Time for Current Relay Count(Relay)
30044 0x0027 word CH1 Relay Last Reset Time for Current Relay Count(Relay)
System information (read)
34122 0x1019 1 word GSM/Cellular signal strength Value
34123 0x101A 2 word Cellular IP
34125 0x101C 1 word GSM/Cellular error message code
34126 0x101D 1 word GSM/Cellular status
Virtual Channel
0x30AE-0x30
C1
2x10 words W5340 virtual channel value (in floating format)
Each VC channel occupies 2 words
