ioLogik W5300 The ioAdmin Utility
3-39
ISAKMP phase 1
Operation Mode: Select main mode or aggressive mode to configure the standard negotiation parameters for
IKE Phase 1 of the VPN Tunnel
NAT traversal (NAT-T): Enabling this option will allow IPsec traffic from this endpoint to traverse through the
translation process during NAT. The remote VPN endpoint must also support this feature and it must be enabled
to function properly over the VPN (default = disable)
Encryption mode: Select the VPN ISAKMP phase 1 encryption mode
Authentication mode: Select the VPN ISAKMP phase 1 authentication mode
Diffie-Hellman group: Select the VPN ISAKMP phase 1 DH group. Increasing the DH Group number increases
the level of encryption implemented for PFS.
SA life time (default = 86400): Enter the number of seconds for the VPN ISAKMP phase 1 Lifetime, which
is the period of time to pass before establishing a new IPsec security association (SA) with the remote endpoint.
ISAKMP phase 2
Encryption mode: Select the VPN ISAKMP phase 2 encryption mode.
Authentication mode: Select the VPN ISAKMP phase 2 authentication mode.
Diffie-Hellman group: Select the VPN ISAKMP phase 2 DH group. Increasing the DH Group number increases
the level of encryption implemented for PFS.
SA life time (default = 28800): Enter the number of seconds for the VPN ISAKMP phase 2 Lifetime, which
is the period of time that passes before establishing a new IPsec security association (SA) with the remote
endpoint.
Advanced Settings
Anti-replay: Anti-replay is the method of not allowing an intercepted packet message to be sent to the
recipient multiple times without the original sender knowing (default = Disable).
Dead Peer Detection (DPD): Enable or disable the Dead Peer Detection. DPD is a method of detecting a dead
Internet Key Exchange (IKE) peer. It sends a DPD packet to the peer every 60 seconds with no traffic and
attempts to connect normally. If the DPD packet fails 5 times the VPN will continuously re-establish a
connection (default = Disable).
VPN System Log Events and Error Codes
VPN system log Description
UNLINK_TIME_REACH SA Lifetime timeout
UNLINK_TIME_OUT No response from remote VPN server
UNLINK_NO_PROPASOL The remote VPN server does not have matched VPN settings(proposal)
UNLINK_DPD DPD detecting
IKE_PHASE1_MAIN_START IKE phase1 Main mode starts
IKE_PHASE1_AGGR_START IKE phase1 Aggressive mode starts
IKE_PHASE1_ENCRY_START IKE phase1 VPN tunnel encrypting
IKE_PHASE1_OK Passing the VPN tunnel phase1
IKE_PHASE2_OK Passing the VPN tunnel phase2
IKE_RENEW_START Rekeying
IKE_RENEW_OK Rekey successfully
PHASE1_TIME_REACH Phase1 SA lifetime timeout
OLD_SA_TIME_REACH Earlier SA lifetime is deleted by the ioLogik
REMOTE_DEL_ISAKMP Key of VPN tunnel phase1 is deleted by the remote
REMOTE_DEL_ESP Key of VPN tunnel phase2 is deleted by the remote
REMOTE_DEL_ESP_OLD Earlier SA lifetime is deleted by the remote VPN Server
