ioLogik W5300 SMS Commands
B-2
SMS Command Syntax:
#GetSMS?command_channel=?&command_channel=?...#
#SetSMS?command_channel=X&command_channel=X...#
Details:
1. SMS commands start and end with a “#” sign.
2. Multiple commands can be integrated using an “&” sign.
3. No space or carriage return/linefeed (enter) are allowed between characters.
4. Commands are NOT case sensitive.
5. To query status, use “GetSMS?” after the 1st “#” sign.
a. Use “=?” after a query command (Read, or Read/Write privilege)
6. To control an output, use “SetSMS?” after the 1st “#” sign.
a. Use “=X” after a control command (Read/Write privilege), where X means the actual command
parameters such as 0 (On), 1 (Off), or value (expansion AO channels).
b. The ioLogik will response with the current output status if the commands are received and processed
correctly.
c. Output control is forbidden if the target channel is currently in use by the Click&Go logic. Integrate the
Internal Register function in the Click&Go logic to perform such tasks by controlling the Internal
Registers.
7. The ioLogik will not respond to illegal commands or wrong control parameters.
8. Only the first 140 characters of a response will be kept; the rest will be discarded.
9. SMS message content:
a. Format: ASCII
b. Maximum number characters: 140
SMS Command Table
System Information Commands:
SMS Command Attribute Note
DATE Read Current Date
TIME Read Current Time
IP Read Current LAN IP address
WIP Read Current WAN(Cellular) IP address
LOC Read Server Location
DESC Read Server Description
FWR_V Read Current Firmware Version
MOD_NAME Read Model Name
SN_NUM Read Serial Number
MAC_ADDR Read MAC Address
EXP_MOD_NUM Read Number of attached E1200 modules
EXP_DEV_MOD_TYPE Read Expansion ioLogik E1200 Type
DEV=Device slot number, start index:01
Example:
1. Query ioLogik W5300 system date:
#GetSMS?DATE=?#
2. Query the ioLogik W5300 Server Location:
#GetSMS?LOC=?#
3. Query the ioLogik W5300 Server Time and LAN IP:
#GetSMS?TIME=?&IP=?#
