ioLogik W5300 Factory Default Settings
E-2
Password:
“empty”
Module Name:
“empty”
Module Location:
“empty:
SNMP:
Enable
Community:
Public
Contact:
“empty”
Location:
“empty”
Data Logging
– AI Channel
Logging Per 1min
TFTP Server Address
None
TFTP Server Port
0
Active OPC Server Address
None
Active OPC Server Port
9900
ioLogik W5300 Network Port Usage
Port Type Usage
68 UDP BOOTPC
68 UDP DHCP
69 UDP Export/import file
161 TCP SNMP
502 TCP Modbus Communication
500 UDP IPsec VPN, NAT-T disabled
4500 UDP IPsec VPN, NAT-T enabled
4800 UDP Auto search
9000 TCP Active Message (Default)
9000 UDP Active Message (Default)
9300 TCP ioAdmin
9500 TCP Active OPC server
9900 TCP Active OPC server
