ioLogik W5300 Modbus/TCP Address Mapping
C-11
Reference Address Data Type Description
40312 0x0137 1 word AI Channel 3 Scale Value Lo-Word (float)
40337 0x0150 1 word Internal Register 00 Initial Value
40338 0x0151 1 word Internal Register 01 Initial Value
40339 0x0152 1 word Internal Register 02 Initial Value
40340 0x0153 1 word Internal Register 03 Initial Value
40341 0x0154 1 word Internal Register 04 Initial Value
40342 0x0155 1 word Internal Register 05 Initial Value
40343 0x0156 1 word Internal Register 06 Initial Value
40344 0x0157 1 word Internal Register 07 Initial Value
40345 0x0158 1 word Internal Register 08 Initial Value
40346 0x0159 1 word Internal Register 09 Initial Value
40347 0x015A 1 word Internal Register 10 Initial Value
40348 0x015B 1 word Internal Register 11 Initial Value
40349 0x015C 1 word Internal Register 12 Initial Value
40350 0x015D 1 word Internal Register 13 Initial Value
40351 0x015E 1 word Internal Register 14 Initial Value
40352 0x015F 1 word Internal Register 15 Initial Value
40353 0x0160 1 word Internal Register 16 Initial Value
40354 0x0161 1 word Internal Register 17 Initial Value
40355 0x0162 1 word Internal Register 18 Initial Value
40356 0x0163 1 word Internal Register 19 Initial Value
40357 0x0164 1 word Internal Register 20 Initial Value
40358 0x0165 1 word Internal Register 21 Initial Value
40359 0x0166 1 word Internal Register 22 Initial Value
40360 0x0167 1 word Internal Register 23 Initial Value
40361 0x0168 2 word Time Init 00 Value
40362 0x0169 2 word Time Init 01 Value
40363 0x016A 2 word Time Init 02 Value
40364 0x016B 2 word Time Init 03 Value
40365 0x016C 2 word Time Init 04 Value
40366 0x016D 2 word Time Init 05 Value
40367 0x016E 2 word Time Init 06 Value
40368 0x016F 2 word Time Init 07 Value
40369 0x0170 2 word Time Init 08 Value
40370 0x0171 2 word Time Init 09 Value
40371 0x0172 2 word Time Init 10 Value
40372 0x0173 2 word Time Init 11 Value
40373 0x0174 2 word Time Init 12 Value
40374 0x0175 2 word Time Init 13 Value
40375 0x0176 2 word Time Init 14 Value
40376 0x0177 2 word Time Init 15 Value
40377 0x0178 2 word Time Init 16 Value
40378 0x0179 2 word Time Init 17 Value
40379 0x017A 2 word Time Init 18 Value
40380 0x017B 2 word Time Init 19 Value
40381 0x017C 2 word Time Init 20 Value
40382 0x017D 2 word Time Init 21 Value
40383 0x017E 2 word Time Init 22 Value
40384 0x017F 2 word Time Init 23 Value
40385 0x0180 1 word Timer Interval 00 Value
40386 0x0181 1 word Timer Interval 01 Value
40387 0x0182 1 word Timer Interval 02 Value
