ioLogik W5300 Click&Go Logic
4-16
Internal Register (Float) Settings
Internal Register(Float) can be used as an analog comparison (dynamic throughput setting) and flag with
the Click&Go logic internally or externally. The 28 sets of internal registers (float) can be polled and controlled
by SCADA software using the standard Modbus/TCP format, or implemented to redirect the result of one
Click&Go logic to another. The default value of an internal register is 0.
Register Number Initial Value
Internal Register FloatReg-0 to FloatReg-27 0.000 (4-byte float point)
Working with Logic
Click&Go Logic Basics
The Click&Go Logic panel is available after logging in as administrator. This is where Click&Go logic is
configured. With a set of rules (known as a rule-set) defined through Click&Go, the ioLogik can perform local
and remote I/O control, report I/O status, and actively send out messages, e-mails, or SNMP traps to a host as
soon as the user-defined I/O conditions have been met.
To use Click&Go Logic, start ioAdmin and log in as ioLogik administrator from the Server Settings panel. Once
you are logged in, go to the Click&Go Logic panel. The following screen should appear:
