ioLogik W5300 Click&Go Logic
4-2
To Get a Quick Start…
Below, we highlight a series of entries to provide a quick review for readers already familiar with Click&Go.
I. Overview
• Software Overview
• Click&Go Logic Basics
• Working with the Rules
II. Getting Started
Quickly set up your I/O and global variables so you can start working with rules:
• I/O configuration
• Defining Global Varibles
III. Start Working with the Logic
Learn the basics of Click&Go’s If-Then-Else Logic:
• If Logic
• Then and Else Logic
• Active Rule Set
• Import and Export Your Configuration
Overview
The ioLogik W5300 series system eliminates the need for host computers to continually poll I/O devices for
their status. Instead, the server itself is able to monitor the status of each I/O device and take the appropriate
action when the I/O status satisfies a user-defined condition. For example, the ioLogik could be configured to
send a TCP/UDP message only when the switch attached to DI-0 is turned on. This event-based structure
results in a much improved response time and a much reduced load on the host computer’s CPU and network
bandwidth.
The ioLogik W5300 supports Moxa’s Click&Go Logic. With Click&Go Logic, you can easily and intuitively
configure when and how I/O information is transmitted over the network. Simple IF-Then-Else statements
are used to specify conditions that are required for certain actions to take place. Up to three conditions and
three actions can be combined in a rule, and you can define up to 24 rules. Supported actions include sending
SNMP traps or TCP/UDP messages to up to 10 hosts at a time.
Click&Go Function Comparison Table by Product Line
Click&Go Function ioLogik E2000 ioLogik W5300
Peer-to-Peer Yes No
Remote Action Yes No
CGI Command Yes No
Trigger Logic
IF-Then-Else rule 24 rules 24 rules
Internal Register 24 24 + 28 float points
Timer 24 24
Schedule Yes Yes
Alarms
TCP/UDP Active Message Yes Yes, Unicode support
SNMP Traps Yes Yes
E-Mail Yes Yes, Unicode support
SMS No Yes, Unicode support
