ioLogik W5300 Modbus/TCP Address Mapping
C-31
Reference Address Data Type Description
40189 0x00BC 1 word CH0 DO set/get pwm safe mode wordvalue
Safe Mode Pulse Operate Status 0: Stop 1: Start
40190 0x00BD 1 word CH1 DO set/get pwm safe mode wordvalue
40191 0x00BE 1 word CH2 DO set/get pwm safe mode wordvalue
40192 0x00BF 1 word CH3 DO set/get pwm safe mode wordvalue
40193 0x00C0 1 word CH4 DO set/get pwm safe mode wordvalue
40194 0x00C1 1 word CH5 DO set/get pwm safe mode wordvalue
40195 0x00C2 1 word CH6 DO set/get pwm safe mode wordvalue
40196 0x00C3 1 word CH7 DO set/get pwm safe mode wordvalue
40197 0x00C4 1 word CH8 DO set/get pwm safe mode wordvalue (DIO)
40198 0x00C5 1 word CH9 DO set/get pwm safe mode wordvalue (DIO)
40199 0x00C6 1 word CH10 DO set/get pwm safe mode wordvalue (DIO)
40200 0x00C7 1 word CH11 DO set/get pwm safe mode wordvalue (DIO)
40201 0x00C8 1 word CH0 DI set/get counter start word
Counter Operate Status 0: Stop 1: Start
40202 0x00C9 1 word CH1 DI set/get counter start word
40203 0x00CA 1 word CH2 DI set/get counter start word
40204 0x00CB 1 word CH3 DI set/get counter start word
40205 0x00CC 1 word CH4 DI set/get counter start word
40206 0x00CD 1 word CH5 DI set/get counter start word
40207 0x00CE 1 word CH6 DI set/get counter start word
40208 0x00CF 1 word CH7 DI set/get counter start word
40209 0x00D0 1 word CH8 DI set/get counter start word (DIO)
40210 0x00D1 1 word CH9 DI set/get counter start word (DIO)
40211 0x00D2 1 word CH10 DI set/get counter start word (DIO)
40212 0x00D3 1 word CH11 DI set/get counter start word (DIO)
40213 0x00D4 1 word CH0 DI set/get counter clear word
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40214 0x00D5 1 word CH1 DI set/get counter clear word
40215 0x00D6 1 word CH2 DI set/get counter clear word
40216 0x00D7 1 word CH3 DI set/get counter clear word
40217 0x00D8 1 word CH4 DI set/get counter clear word
40218 0x00D9 1 word CH5 DI set/get counter clear word
40219 0x00DA 1 word CH6 DI set/get counter clear word
40220 0x00DB 1 word CH7 DI set/get counter clear word
40221 0x00DC 1 word CH8 DI set/get counter clear word (DIO)
40222 0x00DD 1 word CH9 DI set/get counter clear word (DIO)
40223 0x00DE 1 word CH10 DI set/get counter clear word (DIO)
40224 0x00DF 1 word CH11 DI set/get counter clear word (DIO)
40225 0x00E0 1 word CH0 DI clear/get overflow word
Read : 0 : Normal
1 : Overflow
Write : 0 : Clear overflow status
1 : Return illegal data value (0x03)
40226 0x00E1 1 word CH1 DI clear/get overflow word
40227 0x00E2 1 word CH2 DI clear/get overflow word
40228 0x00E3 1 word CH3 DI clear/get overflow word
40229 0x00E4 1 word CH4 DI clear/get overflow word
40230 0x00E5 1 word CH5 DI clear/get overflow word
40231 0x00E6 1 word CH6 DI clear/get overflow word
