ioLogik W5300 Modbus/TCP Address Mapping
C-26
Reference Address Data Type Description
34107 0x100A 3 word Ethernet physical address(MAC-ID)
Word 0 Hi byte = 0
Word 0 Lo byte = 1
Word 1 Hi byte = 2
Word 1 Lo byte =3
Word 2 Hi byte = 4
Word 2 Lo byte = 5
MAC-ID is 00-01-02-03-04-05
34111 0x100E 2 word
(ULONG)
System Elapsed Time (in sec)
34113 0x1010 1 word Click&Go Ready to Run Flag
34114 0x1011 16 word Get DI channels that are locked by Click&Go
34115 0x1012 16 word Get DO channels that are locked by Click&Go
34117 0x1014 2 word Get Click&Go revision
34118 0x1015 2 word Get MOS revision
34119 0x1016 1 word Modbus/RTU Unit ID=1
34121 0x1018 1 word MIB Date Value
34122 0x1019 1 word GSM/Cellular signal strength value
34123 0x101A 2 word Cellular IP
34125 0x101C 1 word GSM/Cellular error message code
34126 0x101D 1 word GSM/Cellular status
4xxxx Read/Write Registers (supports functions 3, 6, 16)
Reference Address Data Type Description
40001 0x0000 1 word CH0 DO Pulse Output Count Value Hi-Word
40002 0x0001 1 word CH0 DO Pulse Output Count Value Lo-Word
40003 0x0002 1 word CH1 DO Pulse Output Count Value Hi-Word
40004 0x0003 1 word CH1 DO Pulse Output Count Value Lo- Word
40005 0x0004 1 word CH2 DO Pulse Output Count Value Hi- Word
40006 0x0005 1 word CH2 DO Pulse Output Count Value Lo- Word
40007 0x0006 1 word CH3 DO Pulse Output Count Value Hi- Word
40008 0x0007 1 word CH3 DO Pulse Output Count Value Lo- Word
40009 0x0008 1 word CH4 DO Pulse Output Count Value Hi- Word
40010 0x0009 1 word CH4 DO Pulse Output Count Value Lo- Word
40011 0x000A 1 word CH5 DO Pulse Output Count Value Hi- Word
40012 0x000B 1 word CH5 DO Pulse Output Count Value Lo- Word
40013 0x000C 1 word CH6 DO Pulse Output Count Value Hi- Word
40014 0x000D 1 word CH6 DO Pulse Output Count Value Lo- Word
40015 0x000E 1 word CH7 DO Pulse Output Count Value Hi- Word
40016 0x000F 1 word CH7 DO Pulse Output Count Value Lo- Word
40017 0x0010 1 word CH8 DO Pulse Output Count Value Hi- Word (DIO)
40018 0x0011 1 word CH8 DO Pulse Output Count Value Lo- Word
40019 0x0012 1 word CH9 DO Pulse Output Count Value Hi- Word (DIO)
40020 0x0013 1 word CH9 DO Pulse Output Count Value Lo- Word
40021 0x0014 1 word CH10 DO Pulse Output Count Value Hi-Word (DIO)
40022 0x0015 1 word CH10 DO Pulse Output Count Value Lo- Word
40023 0x0016 1 word CH11 DO Pulse Output Count Value Hi-Word (DIO)
40024 0x0017 1 word CH11 DO Pulse Output Count Value Lo- Word
40025 0x0018 1 word CH0 DO Pulse Low Signal Width Hi- Word
40026 0x0019 1 word CH0 DO Pulse Low Signal Width Lo- Word
40027 0x001A 1 word CH1 DO Pulse Low Signal Width Hi- Word
