ioLogik W5300 Modbus/TCP Address Mapping
C-30
Reference Address Data Type Description
40152 0x0097 1 word CH11 DO set/get poweron wordvalue (DIO)
40153 0x0098 1 word CH0 DO set/get safe mode wordvalue
0: Off 1: On
40154 0x0099 1 word CH1 DO set/get safe mode wordvalue
0: Off 1: On
40155 0x009A 1 word CH2 DO set/get safe mode wordvalue
0: Off 1: On
40156 0x009B 1 word CH3 DO set/get safe mode wordvalue
0: Off 1: On
40157 0x009C 1 word CH4 DO set/get safe mode wordvalue
0: Off 1: On
40158 0x009D 1 word CH5 DO set/get safe mode wordvalue
0: Off 1: On
40159 0x009E 1 word CH6 DO set/get safe mode wordvalue
0: Off 1: On
40160 0x009F 1 word CH7 DO set/get safe mode wordvalue
0: Off 1: On
40161 0x00A0 1 word CH8 DO set/get safe mode wordvalue (DIO)
0: Off 1: On
40162 0x00A1 1 word CH9 DO set/get safe mode wordvalue (DIO)
0: Off 1: On
40163 0x00A2 1 word CH10 DO set/get safe mode wordvalue (DIO)
0: Off 1: On
40164 0x00A3 1 word CH11 DO set/get safe mode wordvalue (DIO)
0: Off 1: On
40165 0x00A4 1 word CH0 DO set/get pwm start wordvalue
(Pulse Operate Status) 0: Stop 1: Start
40166 0x00A5 1 word CH1 DO set/get pwm start wordvalue
40167 0x00A6 1 word CH2 DO set/get pwm start wordvalue
40168 0x00A7 1 word CH3 DO set/get pwm start wordvalue
40169 0x00A8 1 word CH4 DO set/get pwm start wordvalue
40170 0x00A9 1 word CH5 DO set/get pwm start wordvalue
40171 0x00AA 1 word CH6 DO set/get pwm start wordvalue
40172 0x00AB 1 word CH7 DO set/get pwm start wordvalue
40173 0x00AC 1 word CH8 DO set/get pwm start wordvalue (DIO)
40174 0x00AD 1 word CH9 DO set/get pwm start wordvalue (DIO)
40175 0x00AE 1 word CH10 DO set/get pwm start wordvalue (DIO)
40176 0x00AF 1 word CH11 DO set/get pwm start wordvalue (DIO)
40177 0x00B0 1 word CH0 DO set/get pwm poweron wordvalue
0: Stop 1: Start
40178 0x00B1 1 word CH1 DO set/get pwm poweron wordvalue
40179 0x00B2 1 word CH2 DO set/get pwm poweron wordvalue
40180 0x00B3 1 word CH3 DO set/get pwm poweron wordvalue
40181 0x00B4 1 word CH4 DO set/get pwm poweron wordvalue
40182 0x00B5 1 word CH5 DO set/get pwm poweron wordvalue
40183 0x00B6 1 word CH6 DO set/get pwm poweron wordvalue
40184 0x00B7 1 word CH7 DO set/get pwm poweron wordvalue
40185 0x00B8 1 word CH8 DO set/get pwm poweron wordvalue (DIO)
40186 0x00B9 1 word CH9 DO set/get pwm poweron wordvalue (DIO)
40187 0x00BA 1 word CH10 DO set/get pwm poweron wordvalue (DIO)
40188 0x00BB 1 word CH11 DO set/get pwm poweron wordvalue (DIO)
