ioLogik W5300 Modbus/TCP Address Mapping
C-4
Reference Address Data Type Description
00099 0x0062 1 bit CH2 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00100 0x0063 1 bit CH3 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00101 0x0064 1 bit CH4 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00102 0x0065 1 bit CH5 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00103 0x0066 1 bit CH6 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00104 0x0067 1 bit CH7 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00109 0x006C 1 bit CH0 DI Count Trigger
00110 0x006D 1 bit CH1 DI Count Trigger
00111 0x006E 1 bit CH2 DI Count Trigger
00112 0x006F 1 bit CH3 DI Count Trigger
00113 0x0070 1 bit CH4 DI Count Trigger
00114 0x0071 1 bit CH5 DI Count Trigger
00115 0x0072 1 bit CH6 DI Count Trigger
00116 0x0073 1 bit CH7 DI Count Trigger
00121 0x0078 1 bit CH0 DI Power On Status 0: Off 1: On
00122 0x0079 1 bit CH1 DI Power On Status 0: Off 1: On
00123 0x007A 1 bit CH2 DI Power On Status 0: Off 1: On
00124 0x007B 1 bit CH3 DI Power On Status 0: Off 1: On
00125 0x007C 1 bit CH4 DI Power On Status 0: Off 1: On
00126 0x007D 1 bit CH5 DI Power On Status 0: Off 1: On
00127 0x007E 1 bit CH6 DI Power On Status 0: Off 1: On
00128 0x007F 1 bit CH7 DI Power On Status 0: Off 1: On
00133 0x0084 1 bit CH0 DI Safe Pulse Operate Status 0: Off 1: On
00134 0x0085 1 bit CH1 DI Safe Pulse Operate Status 0: Off 1: On
00135 0x0086 1 bit CH2 DI Safe Pulse Operate Status 0: Off 1: On
00136 0x0087 1 bit CH3 DI Safe Pulse Operate Status 0: Off 1: On
00137 0x0088 1 bit CH4 DI Safe Pulse Operate Status 0: Off 1: On
00138 0x0089 1 bit CH5 DI Safe Pulse Operate Status 0: Off 1: On
00139 0x008A 1 bit CH6 DI Safe Pulse Operate Status 0: Off 1: On
