ioLogik W5300 Modbus/TCP Address Mapping
C-10
Reference Address Data Type Description
40100 0x0063 1 word CH3 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40101 0x0064 1 word CH4 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40102 0x0065 1 word CH5 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40103 0x0066 1 word CH6 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40104 0x0067 1 word CH7 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40109 0x006C 1 word CH0 AI set/get Enable 1:Enable , 0: Disable
40110 0x006D 1 word CH1 AI set/get Enable 1:Enable , 0: Disable
40111 0x006E 1 word CH2 AI set/get Enable 1:Enable , 0: Disable
40112 0x006F 1 word CH3 AI set/get Enable 1:Enable , 0: Disable
40285 0x011C 1 word AI Channel 0 Scaling Enable
40286 0x011D 1 word AI Channel 1 Scaling Enable
40287 0x011E 1 word AI Channel 2 Scaling Enable
40288 0x011F 1 word AI Channel 3 Scaling Enable
40289 0x0120 1 word AI Channel 0 RAW Min Value
40290 0x0121 1 word AI Channel 1 RAW Min Value
40291 0x0122 1 word AI Channel 2 RAW Min Value
40292 0x0123 1 word AI Channel 3 RAW Min Value
40293 0x0124 1 word AI Channel 0 RAW Max Value
40294 0x0125 1 word AI Channel 1 RAW Max Value
40295 0x0126 1 word AI Channel 2 RAW Max Value
40296 0x0127 1 word AI Channel 3 RAW Max Value
40297 0x0128 1 word AI Channel 0 Scale Min Value
40298 0x0129 1 word AI Channel 1 Scale Min Value
40299 0x012A 1 word AI Channel 2 Scale Min Value
40300 0x012B 1 word AI Channel 3 Scale Min Value
40301 0x012C 1 word AI Channel 0 Scale Max Value
40302 0x012D 1 word AI Channel 1 Scale Max Value
40303 0x012E 1 word AI Channel 2 Scale Max Value
40304 0x012F 1 word AI Channel 3 Scale Max Value
40305 0x0130 1 word AI Channel 0 Scale Value Hi-Word (float)
40306 0x0131 1 word AI Channel 0 Scale Value Lo-Word (float)
40307 0x0132 1 word AI Channel 1 Scale Value Hi-Word (float)
40308 0x0133 1 word AI Channel 1 Scale Value Lo-Word (float)
40309 0x0134 1 word AI Channel 2 Scale Value Hi-Word (float)
40310 0x0135 1 word AI Channel 2 Scale Value Lo-Word (float)
40311 0x0136 1 word AI Channel 3 Scale Value Hi-Word (float)
