ioLogik W5300 Modbus/TCP Address Mapping
C-32
Reference Address Data Type Description
40232 0x00E7 1 word CH7 DI clear/get overflow word
40233 0x00E8 1 word CH8 DI clear/get overflow word (DIO)
40234 0x00E9 1 word CH9 DI clear/get overflow word (DIO)
40235 0x00EA 1 word CH10 DI clear/get overflow word (DIO)
40236 0x00EB 1 word CH11 DI clear/get overflow word (DIO)
40237 0x00EC 1 word CH0 DI set/get trigger word
0=Low to High, 1=High to Low
40238 0x00ED 1 word CH1 DI set/get trigger word
40239 0x00EE 1 word CH2 DI set/get trigger word
40240 0x00EF 1 word CH3 DI set/get trigger word
40241 0x00F0 1 word CH4 DI set/get trigger word
40242 0x00F1 1 word CH5 DI set/get trigger word
40243 0x00F2 1 word CH6 DI set/get trigger word
40244 0x00F3 1 word CH7 DI set/get trigger word
40245 0x00F4 1 word CH8 DI set/get trigger word (DIO)
40246 0x00F5 1 word CH9 DI set/get trigger word (DIO)
40247 0x00F6 1 word CH10 DI set/get trigger word (DIO)
40248 0x00F7 1 word CH11 DI set/get trigger word (DIO)
40249 0x00F8 1 word CH0 DI set/get power on start word
(PowerOn Counter Operate Status)
0: Stop 1: Start
40250 0x00F9 1 word CH1 DI set/get power on start word
40251 0x00FA 1 word CH2 DI set/get power on start word
40252 0x00FB 1 word CH3 DI set/get power on start word
40253 0x00FC 1 word CH4 DI set/get power on start word
40254 0x00FD 1 word CH5 DI set/get power on start word
40255 0x00FE 1 word CH6 DI set/get power on start word
40256 0x00FF 1 word CH7 DI set/get power on start word
40257 0x0100 1 word CH8 DI set/get power on start word (DIO)
40258 0x0101 1 word CH9 DI set/get power on start word (DIO)
40259 0x0102 1 word CH10 DI set/get power on start word (DIO)
40260 0x0103 1 word CH11 DI set/get power on start word (DIO)
40261 0x0104 1 word CH0 DI set/get safe start word
(Safe Mode Counter Operate Status)
0: Stop 1: Start
40262 0x0105 1 word CH1 DI set/get safe start word
40263 0x0106 1 word CH2 DI set/get safe start word
40264 0x0107 1 word CH3 DI set/get safe start word
40265 0x0108 1 word CH4 DI set/get safe start word
40266 0x0109 1 word CH5 DI set/get safe start word
40267 0x010A 1 word CH6 DI set/get safe start word
40268 0x010B 1 word CH7 DI set/get safe start word
40269 0x010C 1 word CH8 DI set/get safe start word (DIO)
40270 0x010D 1 word CH9 DI set/get safe start word (DIO)
40271 0x010E 1 word CH10 DI set/get safe start word (DIO)
40272 0x010F 1 word CH11 DI set/get safe start word (DIO)
40273 0x0110 1 word CH0 Power-off storage enable
(DI count value recorded when power-off)
1:ON 0:OFF
40274 0x0111 1 word CH1 Power-off storage enable
40275 0x0112 1 word CH2 Power-off storage enable
40276 0x0113 1 word CH3 Power-off storage enable
