ioLogik W5300 Modbus/TCP Address Mapping
C-15
Reference Address Data Type Description
40518 0x0205 1 word Virtual CH5 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40519 0x0206 1 word Virtual CH6 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06 : 0 -150mV
07 : 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40520 0x0207 1 word Virtual CH7 AI Range
00 : +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06 : 0 -150mV
07 : 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
Internal Register (Integer)
412840 0x3227 Word Internal Registers 00 Working Value
412841 0x3228 Word Internal Registers 01 Working Value
412842 0x3229 Word Internal Registers 02 Working Value
412843 0x322A Word Internal Registers 03 Working Value
412844 0x322B Word Internal Registers 04 Working Value
412845 0x322C Word Internal Registers 05 Working Value
412846 0x322D Word Internal Registers 06 Working Value
412847 0x322E Word Internal Registers 07 Working Value
412848 0x322F Word Internal Registers 08 Working Value
412849 0x3230 Word Internal Registers 09 Working Value
412850 0x3231 Word Internal Registers 10 Working Value
412851 0x3232 Word Internal Registers 11 Working Value
412852 0x3233 Word Internal Registers 12 Working Value
412853 0x3234 Word Internal Registers 13 Working Value
412854 0x3235 Word Internal Registers 14 Working Value
412855 0x3236 Word Internal Registers 15 Working Value
