ioLogik W5300 Modbus/TCP Address Mapping
C-19
ioLogik W5312 Modbus Mapping
NOTE
For Modbus address
es of the ioLogik E1200 expansion modules attached to the ioLogik W5312, check the
ioAdmin
I/O Expansion tabs for details.
0xxxx Read/Write Coils (supports functions 1, 5, 15)
Reference Address Data Type Description
DIO Channels
00001 0x0000 1 bit CH0 DO Value 0: Off 1: On
00002 0x0001 1 bit CH1 DO Value 0: Off 1: On
00003 0x0002 1 bit CH2 DO Value 0: Off 1: On
00004 0x0003 1 bit CH3 DO Value 0: Off 1: On
00005 0x0004 1 bit CH4 DO Value 0: Off 1: On
00006 0x0005 1 bit CH5 DO Value 0: Off 1: On
00007 0x0006 1 bit CH6 DO Value 0: Off 1: On
00008 0x0007 1 bit CH7 DO Value 0: Off 1: On
00009 0x0008 1 bit CH8 DO Value 0: Off 1: On (DIO)
00010 0x0009 1 bit CH9 DO Value 0: Off 1: On (DIO)
00011 0x0010 1 bit CH10 DO Value 0: Off 1: On (DIO)
00012 0x0011 1 bit CH11 DO Value 0: Off 1: On (DIO)
00013 0x000C 1 bit CH0 DO Power On Value 0: Off 1: On
00014 0x000D 1 bit CH1 DO Power On Value 0: Off 1: On
00015 0x000E 1 bit CH2 DO Power On Value 0: Off 1: On
00016 0x000F 1 bit CH3 DO Power On Value 0: Off 1: On
00017 0x0010 1 bit CH4 DO Power On Value 0: Off 1: On
00018 0x0011 1 bit CH5 DO Power On Value 0: Off 1: On
00019 0x0012 1 bit CH6 DO Power On Value 0: Off 1: On
00020 0x0013 1 bit CH7 DO Power On Value 0: Off 1: On
00021 0x0014 1 bit CH8 DO Power On Value 0: Off 1: On (DIO)
00022 0x0015 1 bit CH9 DO Power On Value 0: Off 1: On (DIO)
00023 0x0016 1 bit CH10 DO Power On Value 0: Off 1: On (DIO)
00024 0x0017 1 bit CH11 DO Power On Value 0: Off 1: On (DIO)
00037 0x0024 1 bit CH0 DO Pulse Operate Status 0: Off 1: On
00038 0x0025 1 bit CH1 DO Pulse Operate Status 0: Off 1: On
00039 0x0026 1 bit CH2 DO Pulse Operate Status 0: Off 1: On
00040 0x0027 1 bit CH3 DO Pulse Operate Status 0: Off 1: On
00041 0x0028 1 bit CH4 DO Pulse Operate Status 0: Off 1: On
00042 0x0029 1 bit CH5 DO Pulse Operate Status 0: Off 1: On
00043 0x002A 1 bit CH6 DO Pulse Operate Status 0: Off 1: On
00044 0x002B 1 bit CH7 DO Pulse Operate Status 0: Off 1: On
00045 0x002C 1 bit CH8 DO Pulse Operate Status 0: Off 1: On (DIO)
00046 0x002D 1 bit CH9 DO Pulse Operate Status 0: Off 1: On (DIO)
00047 0x002E 1 bit CH10 DO Pulse Operate Status 0: Off 1: On (DIO)
00048 0x002F 1 bit CH11 DO Pulse Operate Status 0: Off 1: On (DIO)
00049 0x0030 1 bit CH0 DO PowerOn Pulse Operate Status 0: Off 1: On
00050 0x0031 1 bit CH1 DO PowerOn Pulse Operate Status 0: Off 1: On
00051 0x0032 1 bit CH2 DO PowerOn Pulse Operate Status 0: Off 1: On
00052 0x0033 1 bit CH3 DO PowerOn Pulse Operate Status 0: Off 1: On
00053 0x0034 1 bit CH4 DO PowerOn Pulse Operate Status 0: Off 1: On
00054 0x0035 1 bit CH5 DO PowerOn Pulse Operate Status 0: Off 1: On
