ioLogik W5300 Modbus/TCP Address Mapping
C-25
Reference Address Data Type Description
30016 0x000F word CH7 DI Counter Value Lo- Word
30017 0x0010 word CH8 DI Counter Value Hi- Word (DIO)
30018 0x0011 word CH8 DI Counter Value Lo- Word
30019 0x0012 word CH9 DI Counter Value Hi- Word (DIO)
30020 0x0013 word CH9 DI Counter Value Lo- Word
30021 0x0014 word CH10 DI Counter Value Hi- Word (DIO)
30022 0x0015 word CH10 DI Counter Value Lo- Word
30023 0x0016 word CH11 DI Counter Value Hi- Word (DIO)
30024 0x0017 word CH11 DI Counter Value Lo- Word
System Information (read)
34097 0x1000(4096) 1 word Vendor ID=0x1393
34098 0x1001(4097) 1 word Unit ID (Ethernet=1)
34099 0x1002(4098) 1 word Product Code=0x5312
34100 0x1003 20 word Vendor name string=“Moxa Technologies Inc.,”
Word 0 Hi byte = ‘M’(0x4D)
Word 0 Lo byte = ‘o’ (0x6F)
Word 1 Hi byte = ‘x’ (0x78)
Word 1 Lo byte = ‘a’ (0x61)
…
Word 10 Hi byte = ‘c’
Word 10 Lo byte = ‘.’
Word 11 Hi byte = ‘,’
Word 11 Lo byte = ‘\0’
…
String ending next byte value is 0
34101 0x1004 20 word Product name string=W5312 Cellular Micro RTU Controllers
Word 0 Hi byte = ‘W’ (0x57)
Word 0 Lo byte = ‘5’ (0x35)
Word 1 Hi byte = ‘3’ (0x33)
Word 1 Lo byte = ‘1’ (0x34)
…
Word 10 Hi byte = ‘v’
Word 10 Lo byte = ‘e’
Word 11 Hi byte = ‘r’
Word 11 Lo byte = ‘\0’
…
34102 0x1005 2 word Product serial number (decimal)
34103 0x1006 2 word Firmware revision:
Word 0 Hi byte = major (A)
Word 0 Lo byte = minor (B)
Word 1 Hi byte = release (C)
Word 1 Lo byte = build (D)
format is A.B.C.D
34104 0x1007 2 word Firmware release date
Ex. High word = 0x2009
Low word = 0x1231
firmware release date is Dec. 31, 2009
34105 0x1008 1 word Number of TCP connected
34106 0x1009 1 word Ethernet Interface speed, 0x10(10Mbps) or
0x100(100Mbps)
