ioLogik W5300 Modbus/TCP Address Mapping
C-17
Reference Address Data Type Description
419456 0x4BFF word Internal Register (Float) 21 Initial Value Lo-Word
419457 0x4C00 word Internal Register (Float) 22 Initial Value Hi-Word
419458 0x4C01 word Internal Register (Float) 22 Initial Value Lo-Word
419459 0x4C02 word Internal Register (Float) 23 Initial Value Hi-Word
419460 0x4C03 word Internal Register (Float) 23 Initial Value Lo-Word
419461 0x4C04 word Internal Register (Float) 24 Initial Value Hi-Word
419462 0x4C05 word Internal Register (Float) 24 Initial Value Lo-Word
419463 0x4C06 word Internal Register (Float) 25 Initial Value Hi-Word
419464 0x4C07 word Internal Register (Float) 25 Initial Value Lo-Word
419465 0x4C08 word Internal Register (Float) 26 Initial Value Hi-Word
419466 0x4C09 word Internal Register (Float) 26 Initial Value Lo-Word
419467 0x4C0A word Internal Register (Float) 27 Initial Value Hi-Word
419468 0x4C0B word Internal Register (Float) 27 Initial Value Lo-Word
419469 0x4C0C word Internal Register (Float) 00 Working Value Hi-Word
419470 0x4C0D word Internal Register (Float) 00 Working Value Lo-Word
419471 0x4C0E word Internal Register (Float) 01 Working Value Hi-Word
419472 0x4C0F word Internal Register (Float) 01 Working Value Lo-Word
419473 0x4C10 word Internal Register (Float) 02 Working Value Hi-Word
419474 0x4C11 word Internal Register (Float) 02 Working Value Lo-Word
419475 0x4C12 word Internal Register (Float) 03 Working Value Hi-Word
419476 0x4C13 word Internal Register (Float) 03 Working Value Lo-Word
419477 0x4C14 word Internal Register (Float) 04 Working Value Hi-Word
419478 0x4C15 word Internal Register (Float) 04 Working Value Lo-Word
419479 0x4C16 word Internal Register (Float) 05 Working Value Hi-Word
419480 0x4C17 word Internal Register (Float) 05 Working Value Lo-Word
419481 0x4C18 word Internal Register (Float) 06 Working Value Hi-Word
419482 0x4C19 word Internal Register (Float) 06 Working Value Lo-Word
419483 0x4C1A word Internal Register (Float) 07 Working Value Hi-Word
419484 0x4C1B word Internal Register (Float) 07 Working Value Lo-Word
419485 0x4C1C word Internal Register (Float) 08 Working Value Hi-Word
419486 0x4C1D word Internal Register (Float) 08 Working Value Lo-Word
419487 0x4C1E word Internal Register (Float) 09 Working Value Hi-Word
419488 0x4C1F word Internal Register (Float) 09 Working Value Lo-Word
419489 0x4C20 word Internal Register (Float) 10 Working Value Hi-Word
419490 0x4C21 word Internal Register (Float) 10 Working Value Lo-Word
419491 0x4C22 word Internal Register (Float) 11 Working Value Hi-Word
419492 0x4C23 word Internal Register (Float) 11 Working Value Lo-Word
419493 0x4C24 word Internal Register (Float) 12 Working Value Hi-Word
419494 0x4C25 word Internal Register (Float) 12 Working Value Lo-Word
419495 0x4C26 word Internal Register (Float) 13 Working Value Hi-Word
419496 0x4C27 word Internal Register (Float) 13 Working Value Lo-Word
419497 0x4C28 word Internal Register (Float) 14 Working Value Hi-Word
419498 0x4C29 word Internal Register (Float) 14 Working Value Lo-Word
419499 0x4C2A word Internal Register (Float) 15 Working Value Hi-Word
419500 0x4C2B word Internal Register (Float) 15 Working Value Lo-Word
419501 0x4C2C word Internal Register (Float) 16 Working Value Hi-Word
419502 0x4C2D word Internal Register (Float) 16 Working Value Lo-Word
419503 0x4C2E word Internal Register (Float) 17 Working Value Hi-Word
419504 0x4C2F word Internal Register (Float) 17 Working Value Lo-Word
419505 0x4C30 word Internal Register (Float) 18 Working Value Hi-Word
419506 0x4C31 word Internal Register (Float) 18 Working Value Lo-Word
419507 0x4C32 word Internal Register (Float) 19 Working Value Hi-Word
