Moxa ioLogik W5340-HSPA [28/194] Import export a configuration file

ioLogik W5300 Getting Started

2-14

Import/Export a Configuration File

Using ioAdmin to Import/Export a Device Configuration

To import or export a system configuration right click on the I/O model name and then selection Import

System Config or Export System Config. You must be logged in as an administrator to use this command.

Export System Config

Select this command to export the selected ioLogik’s configuration to a text file. We recommend using this

method to back up your configuration after you have finished configuring the ioLogik for your application.

ATTENTION

Since there are major functional differences between firmware versions, exporting the configuration file

requires a longer processing time.

Adjust the TCP Socket Timeout Interval to 30 seconds when using

ioAdmin 3.10 or above, especially if earlier versions of ioAdmin have been installed and then

removed.

Import System Config

Select this command to load a configuration for the selected ioLogik from a configuration text file. The new

configuration will not take effect until the ioLogik has been restarted. This command can be used to restore a

configuration after loading the factory defaults, or to duplicate a configuration to multiple ioLogik units.

ATTENTION

Since

there are major function differences

between firmware versions, the configuration file is not compatible

if using firmware V1.3 or above for the ioLogik W5312 series, and V1.5 or above for the ioLogik W5340 series.

The configuration file cannot be im

ported into firmware versions earlier than the above versions.

Be sure to check your firmware version carefully before importing/exporting and upgrading

firmware.
