ioLogik W5300 Modbus/TCP Address Mapping
C-6
Reference Address Data Type Description
00163 0x00A2 1 bit DIO 06
1: OUTPUT
0: INPUT (Default: OUTPUT)
00164 0x00A3 1 bit DIO 07
1: OUTPUT
0: INPUT (Default: OUTPUT)
AI Channels
00257 0x0100 1bit Reset CH0 AI Min Value
Read: always 0
Write : 1: reset AI Min value
0: return Illegal Data Value
00258 0x0101 1bit Reset CH1 AI Min Value
Read: always 0
Write : 1: reset AI Min value
0: return Illegal Data Value
00259 0x0102 1bit Reset CH2 AI Min Value
Read: always 0
Write : 1: reset AI Min value
0: return Illegal Data Value
00260 0x0103 1bit Reset CH3 AI Min Value
Read: always 0
Write : 1: reset AI Min value
0: return Illegal Data Value
00265 0x0104 1bit Reset CH0 AI Max Value
Read: always 0
Write : 1: reset AI Max value
0: return Illegal Data Value
00266 0x0105 1bit Reset CH1 AI Max Value
Read: always 0
Write : 1: reset AI Max value
0: return Illegal Data Value
00267 0x0106 1bit Reset CH2 AI Max Value
Read: always 0
Write : 1: reset AI Max value
0: return Illegal Data Value
00268 0x0107 1bit Reset CH3 AI Max Value
Read: always 0
Write : 1: reset AI Max value
0: return Illegal Data Value
1xxxx Read only Coils (supports function 2)
Reference Address Data Type Description
10001 0x0000 1 bit CH0 DI Value
10002 0x0001 1 bit CH1 DI Value
10003 0x0002 1 bit CH2 DI Value
10004 0x0003 1 bit CH3 DI Value
10005 0x0004 1 bit CH4 DI Value
10006 0x0005 1 bit CH5 DI Value
10007 0x0006 1 bit CH6 DI Value
10008 0x0007 1 bit CH7 DI Value
