Moxa ioLogik W5340-HSPA [193/194] Cellular modem error codes
![Moxa ioLogik W5340-T [193/194] Cellular modem error codes](/views2/1201254/page193/bgc1.png)
ioLogik W5300 Troubleshooting the Cellular I/O Connection
F-2
ioAdmin
1. Is the AOPC IP Address correc? □ Yes, IP:_________________ □ No
2. Is the GPRS/Link LED a steady green? □ Yes □ No
3. What status is shown on ioAdmin’s Cellular Dial Up setting tab? ____________
4. Check the RSSI Level: _______________
5. Where ioAdmin show an error code? □ If yes, _______________ □ No
6. Does ioAdmin show the Cellular IP address? □ If yes, IP: __________ □ If No, contact your carrier
7. Operation Mode: □ Always On □On Demand
Active OPC server (AOPC):
1. Check the Firewall. Port 9900 (AOPC), 9500, 9300, 502 should be open
2. Is the AOPC IP address on the Cellular dial up setting Tab correct? □ Yes, IP:_________ □ No
3. Check the AOPC log window. Do you see a message? □ Yes, _____________ □ No, nothing special
4. Does AOPC’s tree view show the device? □ Yes □ No
5. Does ioAdmin show the AOPC after adding AOPC manually? □ Yes □ No
6. Choose “sort by AOPC” in ioAdmin. Does ioAdmin show the AOPC? □ Yes □ No
7. Does ioAdmin show the device in the AOPC list? □ Yes □ No
8. Can you ping the AOPC IP address? □ Yes, Time:___________ms □ No. How to ping AOPC?
Client Test:
1. Did you install OPC core components in your PC? □ Yes □ No
2. Were AOPC and the Client tested on the same PC? □ Yes □ No, please install them
3. Did you create an Active Tag in ioAdmin? □ Yes, □ No
4. Does Client test connect to AOPC? □ Yes □ No. Error Message:________________
Remote Client test:
1. Are the AOPC PC and Client test PC on same Domain? □ Yes □ No
2. Are the AOPC PC’s firewall, security, and authorization settings set? □ Yes, check the port setting and user
group settings □ No
3. What kind of Error Message is displayed when you use Client test? ___________________
4. Please return the completed form to Moxa.
Cellular modem error codes:
Error Code Phenomena Display Message
0 Cellular Module_OK No Error
1 Cellular Module without SIM Card No SIM Card Installed
2 Cellular_Module with Error PIN Code PIN Code Error
3 Cellular_Module can’t detected Error Code 3
4 Can’t registration Cellular Network Error Code 4
5 Cellular_Module Parameters Incorrectly Error Code 5
6 Cellular_Module Busy Error Code 6
7 APN incorrectly Wrong APN Setting
8 Dial to Cellular fail dial to Cellular fail
9 PPP Connect fail PPP connect fail
10 Cellular_Module is not Ready Error Code 10
11 Initiate UART port error Error Code 11
12 No any incoming call in Queue Error Code 12
13 Communication Timeout between CPU and Module Error Code 13
14 Unknown Fail Error Code 13
