ioLogik W5300 Modbus/TCP Address Mapping
C-38
Reference Address Data Type Description
419503 0x4C2E word Internal Register (Float) 17 Working Value Hi-Word
419504 0x4C2F word Internal Register (Float) 17 Working Value Lo-Word
419505 0x4C30 word Internal Register (Float) 18 Working Value Hi-Word
419506 0x4C31 word Internal Register (Float) 18 Working Value Lo-Word
419507 0x4C32 word Internal Register (Float) 19 Working Value Hi-Word
419508 0x4C33 word Internal Register (Float) 19 Working Value Lo-Word
419509 0x4C34 word Internal Register (Float) 20 Working Value Hi-Word
419510 0x4C35 word Internal Register (Float) 20 Working Value Lo-Word
419511 0x4C36 word Internal Register (Float) 21 Working Value Hi-Word
419512 0x4C37 word Internal Register (Float) 21 Working Value Lo-Word
419513 0x4C38 word Internal Register (Float) 22 Working Value Hi-Word
419514 0x4C39 word Internal Register (Float) 22 Working Value Lo-Word
419515 0x4C3A word Internal Register (Float) 23 Working Value Hi-Word
419516 0x4C3B word Internal Register (Float) 23 Working Value Lo-Word
419517 0x4C3C word Internal Register (Float) 24 Working Value Hi-Word
419518 0x4C3D word Internal Register (Float) 24 Working Value Lo-Word
419519 0x4C3E word Internal Register (Float) 25 Working Value Hi-Word
419520 0x4C3F word Internal Register (Float) 25 Working Value Lo-Word
419521 0x4C40 word Internal Register (Float) 26 Working Value Hi-Word
419522 0x4C41 word Internal Register (Float) 26 Working Value Lo-Word
419523 0x4C42 word Internal Register (Float) 27 Working Value Hi-Word
419524 0x4C43 word Internal Register (Float) 27 Working Value Lo-Word
419525 0x4C44 10 word Internal Register (Float) 00 Description
419526 0x4C45 10 word Internal Register (Float) 01 Description
419527 0x4C46 10 word Internal Register (Float) 02 Description
419528 0x4C47 10 word Internal Register (Float) 03 Description
419529 0x4C48 10 word Internal Register (Float) 04 Description
419530 0x4C49 10 word Internal Register (Float) 05 Description
419531 0x4C4A 10 word Internal Register (Float) 06 Description
419532 0x4C4B 10 word Internal Register (Float) 07 Description
419533 0x4C4C 10 word Internal Register (Float) 08 Description
419534 0x4C4D 10 word Internal Register (Float) 09 Description
419535 0x4C4E 10 word Internal Register (Float) 10 Description
419536 0x4C4F 10 word Internal Register (Float) 11 Description
419537 0x4C50 10 word Internal Register (Float) 12 Description
419538 0x4C51 10 word Internal Register (Float) 13 Description
419539 0x4C52 10 word Internal Register (Float) 14 Description
419540 0x4C53 10 word Internal Register (Float) 15 Description
419541 0x4C54 10 word Internal Register (Float) 16 Description
419542 0x4C55 10 word Internal Register (Float) 17 Description
419543 0x4C56 10 word Internal Register (Float) 18 Description
419544 0x4C57 10 word Internal Register (Float) 19 Description
419545 0x4C58 10 word Internal Register (Float) 20 Description
419546 0x4C59 10 word Internal Register (Float) 21 Description
419547 0x4C5A 10 word Internal Register (Float) 22 Description
419548 0x4C5B 10 word Internal Register (Float) 23 Description
419549 0x4C5C 10 word Internal Register (Float) 24 Description
419550 0x4C5D 10 word Internal Register (Float) 25 Description
419551 0x4C5E 10 word Internal Register (Float) 26 Description
419552 0x4C5F 10 word Internal Register (Float) 27 Description
