ioLogik W5300 Modbus/TCP Address Mapping
C-13
Reference Address Data Type Description
40440 0x01B7 10 word Internal Register Description 07 Value
40441 0x01B8 10 word Internal Register Description 08 Value
40442 0x01B9 10 word Internal Register Description 09 Value
40443 0x01BA 10 word Internal Register Description 10 Value
40444 0x01BB 10 word Internal Register Description 11 Value
40445 0x01BC 10 word Internal Register Description 12 Value
40446 0x01BD 10 word Internal Register Description 13 Value
40447 0x01BE 10 word Internal Register Description 14 Value
40418 0x01BF 10 word Internal Register Description 15 Value
40419 0x01C0 10 word Internal Register Description 16 Value
40420 0x01C1 10 word Internal Register Description 17 Value
40421 0x01C2 10 word Internal Register Description 18 Value
40422 0x01C3 10 word Internal Register Description 19 Value
40423 0x01C4 10 word Internal Register Description 20 Value
40424 0x01C5 10 word Internal Register Description 21 Value
40425 0x01C6 10 word Internal Register Description 22 Value
40426 0x01C7 10 word Internal Register Description 23 Value
40427 0x01C8 1 word Message Retry Times
40428 0x01C9 1 word Message Retry Interval
40429 0x01CA 1 word Mail Retry Times
40430 0x01CB 1 word Mail Retry Interval
40431 0x01CC 1 word SMS Retry Times
40432 0x01CD 1 word SMS Retry Interval
40577 0x0240 20 word Message Server Address 00
40578 0x0241 20 word Message Server Address 01
40579 0x0242 20 word Message Server Address 02
40580 0x0243 20 word Message Server Address 03
40581 0x0244 20 word Message Server Address 04
40582 0x0245 20 word Message Server Address 05
40583 0x0246 20 word Message Server Address 06
40584 0x0247 20 word Message Server Address 07
40585 0x0248 20 word Message Server Address 08
40586 0x0249 20 word Message Server Address 09
48962 0x2301 2 word CH8 DO Current Relay Count Value
48963 0x2302 2 word CH9 DO Current Relay Count Value
40513 0x0200 1 word CH0 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
