ioLogik W5300 Modbus/TCP Address Mapping
C-8
4xxxx Read/Write Registers (supports functions 3, 6, 16)
Reference Address Data Type Description
40001 0x0000 1 word CH0 DO Pulse Output Count Value Hi-Word
40002 0x0001 1 word CH0 DO Pulse Output Count Value Lo-Word
40003 0x0002 1 word CH1 DO Pulse Output Count Value Hi-Word
40004 0x0003 1 word CH1 DO Pulse Output Count Value Lo- Word
40005 0x0004 1 word CH2 DO Pulse Output Count Value Hi- Word
40006 0x0005 1 word CH2 DO Pulse Output Count Value Lo- Word
40007 0x0006 1 word CH3 DO Pulse Output Count Value Hi- Word
40008 0x0007 1 word CH3 DO Pulse Output Count Value Lo- Word
40009 0x0008 1 word CH4 DO Pulse Output Count Value Hi- Word
40010 0x0009 1 word CH4 DO Pulse Output Count Value Lo- Word
40011 0x000A 1 word CH5 DO Pulse Output Count Value Hi- Word
40012 0x000B 1 word CH5 DO Pulse Output Count Value Lo- Word
40013 0x000C 1 word CH6 DO Pulse Output Count Value Hi- Word
40014 0x000D 1 word CH6 DO Pulse Output Count Value Lo- Word
40015 0x000E 1 word CH7 DO Pulse Output Count Value Hi- Word
40016 0x000F 1 word CH7 DO Pulse Output Count Value Lo- Word
40017 0x0010 1 word CH8 DO Pulse Output Count Value Hi- Word (Relay)
40018 0x0011 1 word CH8 DO Pulse Output Count Value Lo- Word (Relay)
40019 0x0012 1 word CH9 DO Pulse Output Count Value Hi- Word (Relay)
40020 0x0013 1 word CH9 DO Pulse Output Count Value Lo- Word (Relay)
40025 0x0018 1 word CH0 DO Pulse Low Signal Width Hi- Word
40026 0x0019 1 word CH0 DO Pulse Low Signal Width Lo- Word
40027 0x001A 1 word CH1 DO Pulse Low Signal Width Hi- Word
40028 0x001B 1 word CH1 DO Pulse Low Signal Width Lo- Word
40029 0x001C 1 word CH2 DO Pulse Low Signal Width Hi- Word
40030 0x001D 1 word CH2 DO Pulse Low Signal Width Lo- Word
40031 0x001E 1 word CH3 DO Pulse Low Signal Width Hi- Word
40032 0x001F 1 word CH3 DO Pulse Low Signal Width Lo- Word
40033 0x0020 1 word CH4 DO Pulse Low Signal Width Hi- Word
40034 0x0021 1 word CH4 DO Pulse Low Signal Width Lo- Word
40035 0x0022 1 word CH5 DO Pulse Low Signal Width Hi- Word
40036 0x0023 1 word CH5 DO Pulse Low Signal Width Lo- Word
40037 0x0024 1 word CH6 DO Pulse Low Signal Width Hi- Word
40038 0x0025 1 word CH6 DO Pulse Low Signal Width Lo- Word
40039 0x0026 1 word CH7 DO Pulse Low Signal Width Hi- Word
40040 0x0027 1 word CH7 DO Pulse Low Signal Width Lo- Word
40041 0x0028 1 word CH8 DO Pulse Low Signal Width Hi- Word (Relay)
40042 0x0029 1 word CH8 DO Pulse Low Signal Width Lo- Word (Relay)
40043 0x002A 1 word CH9 DO Pulse Low Signal Width Hi- Word (Relay)
40044 0x002B 1 word CH9 DO Pulse Low Signal Width Lo- Word (Relay)
40049 0x0030 1 word CH0 DO Pulse High Signal Width Hi- Word
40050 0x0031 1 word CH0 DO Pulse High Signal Width Lo- Word
40051 0x0032 1 word CH1 DO Pulse High Signal Width Hi- Word
40052 0x0033 1 word CH1 DO Pulse High Signal Width Lo- Word
40053 0x0034 1 word CH2 DO Pulse High Signal Width Hi- Word
40054 0x0035 1 word CH2 DO Pulse High Signal Width Lo- Word
40055 0x0036 1 word CH3 DO Pulse High Signal Width Hi- Word
40056 0x0037 1 word CH3 DO Pulse High Signal Width Lo- Word
40057 0x0038 1 word CH4 DO Pulse High Signal Width Hi- Word
