ioLogik W5300 Modbus/TCP Address Mapping
C-14
Reference Address Data Type Description
40514 0x0201 1 word CH1 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40515 0x0202 1 word CH2 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40516 0x0203 1 word CH3 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40517 0x0204 1 word Virtual CH4 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06: 0 -150mV
07: 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
