ioLogik W5300 Modbus/TCP Address Mapping
C-5
Reference Address Data Type Description
00140 0x008B 1 bit CH7 DI Safe Pulse Operate Status 0: Off 1: On
00145 0x0090 1 bit CH0 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00146 0x0091 1 bit CH1 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00147 0x0092 1 bit CH2 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00148 0x0093 1 bit CH3 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00149 0x0094 1 bit CH4 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00150 0x0095 1 bit CH5 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00151 0x0096 1 bit CH6 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00152 0x0097 1 bit CH7 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00157 0x009C 1 bit DIO 00
1: OUTPUT
0: INPUT (Default: INPUT)
00158 0x009D 1 bit DIO 01
1: OUTPUT
0: INPUT (Default: INPUT)
00159 0x009E 1 bit DIO 02
1: OUTPUT
0: INPUT (Default: INPUT)
00160 0x009F 1 bit DIO 03
1: OUTPUT
0: INPUT (Default: INPUT)
00161 0x00A0 1 bit DIO 04
1: OUTPUT
0: INPUT (Default: OUTPUT)
00162 0x00A1 1 bit DIO 05
1: OUTPUT
0: INPUT (Default: OUTPUT)
