ioLogik W5300 Modbus/TCP Address Mapping
C-24
Reference Address Data Type Description
00156 0x009B 1 bit CH11 DI set channel (DIO)
Power-off storage enable ON/OFF
1:ON
0:OFF
00165 0x00A4 1 bit DIO 8 Set DIO direction
1: OUTPUT
0: INPUT (Default: INPUT)
00166 0x00A5 1 bit DIO 9 Set DIO direction
1: OUTPUT
0: INPUT (Default: INPUT)
00167 0x00A6 1 bit DIO 10 Set DIO direction
1: OUTPUT
0: INPUT (Default: INPUT)
00168 0x00A7 1 bit DIO 11 Set DIO direction
1: OUTPUT
0: INPUT (Default: INPUT)
1xxxx Read only Coils (supports function 2)
Reference Address Data Type Description
10001 0x0000 1 bit CH0 DI Value
10002 0x0001 1 bit CH1 DI Value
10003 0x0002 1 bit CH2 DI Value
10004 0x0003 1 bit CH3 DI Value
10005 0x0004 1 bit CH4 DI Value
10006 0x0005 1 bit CH5 DI Value
10007 0x0006 1 bit CH6 DI Value
10008 0x0007 1 bit CH7 DI Value
10009 0x0008 1 bit CH8 DI Value (DIO)
10010 0x0009 1 bit CH9 DI Value (DIO)
10011 0x000A 1 bit CH10 DI Value (DIO)
10012 0x000B 1 bit CH11 DI Value (DIO)
3xxxx Read only Registers (supports function 4)
Reference Address Data Type Description
30001 0x0000 word CH0 DI Counter Value Hi- Word
30002 0x0001 word CH0 DI Counter Value Lo- Word
30003 0x0002 word CH1 DI Counter Value Hi- Word
30004 0x0003 word CH1 DI Counter Value Lo- Word
30005 0x0004 word CH2 DI Counter Value Hi- Word
30006 0x0005 word CH2 DI Counter Value Lo- Word
30007 0x0006 word CH3 DI Counter Value Hi- Word
30008 0x0007 word CH3 DI Counter Value Lo- Word
30009 0x0008 word CH4 DI Counter Value Hi- Word
30010 0x0009 word CH4 DI Counter Value Lo- Word
30011 0x000A word CH5 DI Counter Value Hi- Word
30012 0x000B word CH5 DI Counter Value Lo- Word
30013 0x000C word CH6 DI Counter Value Hi- Word
30014 0x000D word CH6 DI Counter Value Lo- Word
30015 0x000E word CH7 DI Counter Value Hi- Word
