ioLogik W5300 Modbus/TCP Address Mapping
C-34
Reference Address Data Type Description
40381 0x017C 2 word Time Init 20 Value
40382 0x017D 2 word Time Init 21 Value
40383 0x017E 2 word Time Init 22 Value
40384 0x017F 2 word Time Init 23 Value
40385 0x0180 1 word Timer Interval 00 Value
40386 0x0181 1 word Timer Interval 01 Value
40387 0x0182 1 word Timer Interval 02 Value
40388 0x0183 1 word Timer Interval 03 Value
40389 0x0184 1 word Timer Interval 04 Value
40390 0x0185 1 word Timer Interval 05 Value
40391 0x0186 1 word Timer Interval 06 Value
40392 0x0187 1 word Timer Interval 07 Value
40393 0x0188 1 word Timer Interval 08 Value
40394 0x0189 1 word Timer Interval 09 Value
40395 0x018A 1 word Timer Interval 10 Value
40396 0x018B 1 word Timer Interval 11 Value
40397 0x018C 1 word Timer Interval 12 Value
40398 0x018D 1 word Timer Interval 13 Value
40399 0x018E 1 word Timer Interval 14 Value
40400 0x018F 1 word Timer Interval 15 Value
40401 0x0190 1 word Timer Interval 16 Value
40402 0x0191 1 word Timer Interval 17 Value
40403 0x0192 1 word Timer Interval 18 Value
40404 0x0193 1 word Timer Interval 19 Value
40405 0x0194 1 word Timer Interval 20 Value
40406 0x0195 1 word Timer Interval 21 Value
40407 0x0196 1 word Timer Interval 22 Value
40408 0x0197 2 word Timer Interval 23 Value
40409 0x0198 10 word Timer Description 00 Value
40410 0x0199 10 word Timer Description 01 Value
40411 0x019A 10 word Timer Description 02 Value
40412 0x019B 10 word Timer Description 03 Value
40413 0x019C 10 word Timer Description 04 Value
40414 0x019D 10 word Timer Description 05 Value
40415 0x019E 10 word Timer Description 06 Value
40416 0x019F 10 word Timer Description 07 Value
40417 0x01A0 10 word Timer Description 08 Value
40418 0x01A1 10 word Timer Description 09 Value
40419 0x01A2 10 word Timer Description 10 Value
40420 0x01A3 10 word Timer Description 11 Value
40421 0x01A4 10 word Timer Description 12 Value
40422 0x01A5 10 word Timer Description 13 Value
40423 0x01A6 10 word Timer Description 14 Value
40424 0x01A7 10 word Timer Description 15 Value
40425 0x01A8 10 word Timer Description 16 Value
40426 0x01A9 10 word Timer Description 17 Value
40427 0x01AA 10 word Timer Description 18 Value
40428 0x01AB 10 word Timer Description 19 Value
40429 0x01AC 10 word Timer Description 20 Value
40430 0x01AD 10 word Timer Description 21 Value
40431 0x01AE 10 word Timer Description 22 Value
40432 0x01AF 10 word Timer Description 23 Value
