ioLogik W5300 Modbus/TCP Address Mapping
C-36
Reference Address Data Type Description
412851 0x3232 Word Internal Registers 11 Working Value
412852 0x3233 Word Internal Registers 12 Working Value
412853 0x3234 Word Internal Registers 13 Working Value
412854 0x3235 Word Internal Registers 14 Working Value
412855 0x3236 Word Internal Registers 15 Working Value
412856 0x3237 Word Internal Registers 16 Working Value
412857 0x3238 Word Internal Registers 17 Working Value
412858 0x3239 Word Internal Registers 18 Working Value
412859 0x323A Word Internal Registers 19 Working Value
412860 0x323B Word Internal Registers 20 Working Value
412861 0x323C Word Internal Registers 21 Working Value
412862 0x323D Word Internal Registers 22 Working Value
412863 0x323E Word Internal Registers 23 Working Value
Internal Register (Float)
419413 0x4BD4 word Internal Register (Float) 00 Initial Value Hi-Word
419414 0x4BD5 word Internal Register (Float) 00 Initial Value Lo-Word
419415 0x4BD6 word Internal Register (Float) 01 Initial Value Hi-Word
419416 0x4BD7 word Internal Register (Float) 01 Initial Value Lo-Word
419417 0x4BD8 word Internal Register (Float) 02 Initial Value Hi-Word
419418 0x4BD9 word Internal Register (Float) 02 Initial Value Lo-Word
419419 0x4BDA word Internal Register (Float) 03 Initial Value Hi-Word
419420 0x4BDB word Internal Register (Float) 03 Initial Value Lo-Word
419421 0x4BDC word Internal Register (Float) 04 Initial Value Hi-Word
419422 0x4BDD word Internal Register (Float) 04 Initial Value Lo-Word
419423 0x4BDE word Internal Register (Float) 05 Initial Value Hi-Word
419424 0x4BDF word Internal Register (Float) 05 Initial Value Lo-Word
419425 0x4BE0 word Internal Register (Float) 06 Initial Value Hi-Word
419426 0x4BE1 word Internal Register (Float) 06 Initial Value Lo-Word
419427 0x4BE2 word Internal Register (Float) 07 Initial Value Hi-Word
419428 0x4BE3 word Internal Register (Float) 07 Initial Value Lo-Word
419429 0x4BE4 word Internal Register (Float) 08 Initial Value Hi-Word
419430 0x4BE5 word Internal Register (Float) 08 Initial Value Lo-Word
419431 0x4BE6 word Internal Register (Float) 09 Initial Value Hi-Word
419432 0x4BE7 word Internal Register (Float) 09 Initial Value Lo-Word
419433 0x4BE8 word Internal Register (Float) 10 Initial Value Hi-Word
419434 0x4BE9 word Internal Register (Float) 10 Initial Value Lo-Word
419435 0x4BEA word Internal Register (Float) 11 Initial Value Hi-Word
419436 0x4BEB word Internal Register (Float) 11 Initial Value Lo-Word
419437 0x4BEC word Internal Register (Float) 12 Initial Value Hi-Word
419438 0x4BED word Internal Register (Float) 12 Initial Value Lo-Word
419439 0x4BEE word Internal Register (Float) 13 Initial Value Hi-Word
419440 0x4BEF word Internal Register (Float) 13 Initial Value Lo-Word
419441 0x4BF0 word Internal Register (Float) 14 Initial Value Hi-Word
419442 0x4BF1 word Internal Register (Float) 14 Initial Value Lo-Word
419443 0x4BF2 word Internal Register (Float) 15 Initial Value Hi-Word
419444 0x4BF3 word Internal Register (Float) 15 Initial Value Lo-Word
419445 0x4BF4 word Internal Register (Float) 16 Initial Value Hi-Word
419446 0x4BF5 word Internal Register (Float) 16 Initial Value Lo-Word
419447 0x4BF6 word Internal Register (Float) 17 Initial Value Hi-Word
419448 0x4BF7 word Internal Register (Float) 17 Initial Value Lo-Word
419449 0x4BF8 word Internal Register (Float) 18 Initial Value Hi-Word
419450 0x4BF9 word Internal Register (Float) 18 Initial Value Lo-Word
