11.54
Dismantling engine
•
Attach engine mount, BMW No. 11 0 630, to
engine block.
•
Transfer engine to assembly frame.
•
Drain engine oil.
•
Remove oil filter, using oil filter wrench,
BMW No. 11 4 650.
11 0 630
RS110010
11 4 650
RS110950
