46.27
[RS] Removing and installing wind-
shield
•
Remove windshield.
•
Remove front side sections of fairing.
•
Remove inner fairing cover.
•
Detach instrument cluster.
•
Detach top section of fairing.
•
Remove headlight.
•
Remove bracket (1) for windshield.
•
Install in the reverse order of work.
1
RS460080
