Dismantling/reassembling valve gear
holder
•
Remove bearing cap.
•
Insert a suitable drift into the bore (arrow) of the
rocker shaft, and pull the shaft out of the mount
by twisting it in both directions.
•
Remove pushrods.
e Caution:
Do not accidentally confuse rocker shafts and
pushrods.
M8 x 40
M8 x 30
M8 x 40
RS110080
