BMW R850 1100GS (2000) [228/464] Removing and installing output shaft seal
![BMW R850 1100GS (2000) [228/464] Removing and installing output shaft seal](/views2/1121034/page228/bge4.png)
23.30
Removing and installing output shaft
seal
•
Force out shaft seal with drift, working from the
inside
•
Drive in the new shaft seal with drift and sliding
sleeve, BMW No. 23 4 620.
23 4 620
RS230210
