16.9
Removing and installing fuel filter,
fuel pump and fuel level sensor
e Caution:
Fuel is flammable and a hazard to health.
Observe relevant safety regulations.
•
Drain fuel tank.
•
Remove fuel pump unit (1) and detach hoses (2).
1
2
RS160020
