23.35
e Caution:
To check friction coefficient of taper roller bearings
on input shaft, only install input shaft in
gearbox.
Bearings must be oiled.
Shimming the gearbox shafts (without Clean Bearing)
Example
Dimensions in millimeters Output shaft
"Ab"
Idler shaft
"Zw"
Input shaft
"An"
H 60,00 mm
(2.362 in)
60,00 mm
(2.362 in)
60,00 mm
(2.362 in)
– M (measure!)
=G
D (measure!)
– G
= clearance without spacers
– specified end float 0,05 – 0,15 mm
(0.00196...0.0059 in)
0,05 – 0,15 mm
(0.00196...0.0059 in)
+ permitted preload 0,20 mm (0.00787 in)
= thickness of spacers
Shimming the gearbox shafts (with Clean Bearing)
Example
Dimensions in millimeters Output shaft
"Ab"
Idler shaft
"Zw"
Input shaft
"An"
H 60,00 mm
(2.362 in)
60,00 mm
(2.362 in)
60,00 mm
(2.362 in)
– M (measure!)
=G
D (measure!)
– G
= Clearance without shims and
input-shaft bearing
– specified end float 0,05 – 0,15 mm
(0.00196...0.0059 in)
0,05 – 0,15 mm
(0.00196...0.0059 in)
0,05 – 0,15 mm
(0.00196...0.0059 in)
= Bearing (input shaft)
and shim thickness
