BMW R850 1100GS (2000) [416/464] Frame wiring harness abs
![BMW R850 1100GS (2000) [416/464] Frame wiring harness abs](/views2/1121034/page416/bg1a0.png)
61.9
Frame wiring harness [ABS]
e Caution:
Threaded earth (ground) connection at en-
gine: use galvanized (yellow) screws.
Screws with unsuitable corrosion proofing can
cause the electrical resistance to rise as high as
80
Ω. Run wiring without kinking and avoid risk of
abrasion.
Note the number and position of the cable straps.
•
Apply a thin coating of contact grease, e.g.
CENTOPLEX 3 CU to the central earth (ground)
point, which must be cleaned to bright metal
first.
L Note:
When removing the wiring harness, take out the
central electrical equipment box at the same time.
When installing, fit the central electrical equipment
box first.
X Tightening torque:
Ground (earth) connection to engine ............ 10 Nm
