23.16
Removing/dismantling/reassembling
selector shaft
•
Remove selector shaft (1).
•
Attach sliding sleeve (2), BMW No. 23 4 612, and
pull out selector shaft with washer (3).
23 4 612
2
1
3
RS230060
