23.38
Removing and installing input shaft
seal at housing cover end
•
Drive out shaft sealing ring with punch from the
inside.
•
Drive in the new sealing ring with a drift and
sliding sleeve, BMW No. 23 4 630.
23 4 630
RS230290
