00.4
11 Engine
Connection Nm Nm
Oil filter
Oil filter 11 11
Oil drain plug 32 32
Oil pump
Mesh filter basket to engine block 9 9
Oil pump cover 9 9
Pressure relief valve 35 35
Oil pressure switch 30 30
Oil cooler
Oil cooler pipe to engine block 10 10
Cooling oil line - banjo screw 25 25
Cooling oil line - banjo screw with oil vent valve 25 25
Oil lines to oil cooler 25 –
Oil cooler to holder 9 9
Oil cooler return line to engine block 35 35
Oil cooler feed line to frame 20 20
Oil cooler feed line to engine block 25 25
Screw-in union for oil cooler connection at
engine block
35 35
Clean threads and apply Loctite 603 to inner and
outer threads and in the contact face area
Oil cooler hose at oil thermostat – 40
Cylinders
Tightening sequence
M 8 screw 20 20
M 6 screw 9 9
Chain guide rail pivot screw 18 18
Timing chain
Chain tensioner 32 32
Connecting rod
Big end cap Joint torque 20 20
Additional wrench angle 80°
Crankcase
Tightening sequence:
M 10 screw (oiled) 45 45
M 8 screw (oiled) 20 20
M 6 screw 9 9
Model R 1100 RS R 1100 RT
