11.97
Timing the ignition
•
Prevent clutch housing from moving with TDC
insert pin, BMW No. 11 2 650.
•
Connect ignition tester, BMW No. 12 3 650, and
adapter lead, BMW No. 12 3 652, to magnetic
gate.
•
Turn the Hall-effect gate plate until the telltale
lamp just goes out.
•
Tighten plate on Hall-effect trigger.
•
Remove the TDC insert pin.
11 2 650
TDC
RS110461
12 3 650
12 3 652
RS110460
