Technical Data R 1100 RS
Fuel tank
Tank capacity l (Imp. pints) 23 (40.48)
including reserve of l (Imp. pints) 6 (10.56)
Fuel pump
Type Gear-type
Make VDO
Operating voltage V 12
Fuel pressure bar (psi) 3 (43.512)
Delivery volume l/h (Imp. pints/h) 110 (193.6)
