00.10
46 Frame
Connection Nm Nm
Rear frame to gearbox/engine 47 47
Screw connection on right of gearbo
at right of engine
at left of engine
at left of gearbox
Footrest plate to gearbox 22 22
Frame to engine 82 82
Struts to frame 47
8.8 screw
47
8.8 screw
58
10.9 screw
58
10.9 screw
Struts to engine 47 47
Guard hoop to cylinder head 20 20
Side stand to pivot mount 42 42
clean thread + Loctite 2701
Center stand to carrier plate 21 21
clean thread + Loctite 2701
Carrier plate for center stand to engine block
M12 screw 72 72
clean thread + Loctite 2701
M 8 screw (countersunk) 21 21
clean thread + Loctite 2701
Grab handle to rear frame 9 9
Lifting handle to rear frame 10 10
Footrest plate to rear frame
M 6 screw 9 –
M 8 screw 21 21
M 10 screw 42 –
Footrest to footrest plate 42 –
Fairing support bracket to frame 20 20
Model R 1100 RS R 1100 RT
