23.6
Technical Data R 850 R R 1100 R
Type of gearbox 5-speed gearbox with claw-action shift and
integral reaction damper for all gears
Type of selector mechanism Pedal-operated lever and selector drum with
overshoot detent
Gear ratios
1st gear 4,163 4,163
2nd gear 2,914 2,914
3rd gear 2,133 2,133
4th gear 1,740 1,740
5th gear 1,450 1,450
Oil grade (all the year round) Brand-name SAE 90
hypoid gear oil, API
Class GL 5
Brand-name SAE 90
hypoid gear oil, API
Class GL 5
Filling capacity Initial filling Initial filling
l (Imp. pints) 1.0 (1.76) (to lower edge
of filler screw)
1.0 (1.76) (to lower edge
of filler screw)
When oil is changed When oil is changed
l (Imp. pints) approx. 0.8 (1.408) (to
lower edge of filler
screw)
approx. 0.8 (1.408) (to
lower edge of filler
screw)
End float on idler shaft mm (in) 0,05...0,15
(0.00196...0.0059)
0,05...0,15
(0.00196...0.0059)
End float on output shaft mm (in) 0,05...0,15
(0.00196...0.0059)
0,05...0,15
(0.00196...0.0059)
End float, input shaft (Clean Bearing) mm (in) 0,05...0,15
(0.00196...0.0059)
0,05...0,15
(0.00196...0.0059)
Preload on input shaft 0.2 mm (0.00787)
= 0.5...1.0 Nm frictio
0.2 mm (0.00787)
= 0.5...1.0 Nm frictio
End float at selector drum/deep-groove ball
bearing mm (in) < 0,1 (0.0039) < 0,1 (0.0039)
End float at deep-groove
ball bearing/housing mm (in) < 0,1 (0.0039) < 0,1 (0.0039)
Input-shaft conversion to
Clean Bearing
As of gearbox No.
10483 DAF
10776 DAH
12958 DAK
12650 DAL
12405 DAG
7864 DAJ
131 DCF
101 DCH
As of gearbox No.
10483 DAF
10776 DAH
12958 DAK
12650 DAL
12405 DAG
7864 DAJ
131 DCF
101 DCH
Full conversion to Clean Bearing
BMW No.: 2.325.222...227
As of gearbox No.
101 DAQ
101 DAR
101 DAS
101 DAT
101 DAU
101 DAV
101 DCQ
101 DCR
As of gearbox No.
101 DAQ
101 DAR
101 DAS
101 DAT
101 DAU
101 DAV
101 DCQ
101 DCR
