00.13

11 Engine

Connection Nm Nm

Oil filter

Oil filter 11 11

Oil drain plug 32 32

Oil pump

Mesh filter basket to engine block 9 9

Oil pump cover 9 9

Pressure relief valve 35 35

Oil pressure switch 30 30

Oil cooler

Oil cooler pipe to engine block 10 10

Cooling oil line - banjo screw 25 25

Cooling oil line - banjo screw with oil vent valve 25 25

Oil lines to oil cooler 25 –

Oil cooler to holder 9 9

Oil cooler return line to engine block 35 35

Oil cooler feed line to engine block 25 25

Screw-in union for oil cooler connection at

engine block

35 35

Clean threads and apply Loctite 603 to inner and

outer threads and in the contact face area

Cylinders

Tightening sequence:

1. M 8 screw 20 20

2. M 6 screw 9 9

3. Chain guide rail pivot screw 18 18

Timing chain

Chain tensioner 32 32

Connecting rod

Big end cap Joint torque 20 20

Additional wrench angle 80°

Crankcase

Tightening sequence:

1. M 10 screw (oiled) 45 45

2. M 8 screw (oiled) 20 20

3. M 6 screw 9 9

Model R 850/1100 GS R850/1100R
