33.6
Technical Data R 850 R R 1100 R
Rear wheel drive
Gear tooth pattern Klingelnberg-Palloid spiral bevel
Gear ratios 3.36 : 1 3.00 : 1
Number of teeth 37 : 11 33 : 11
Backlash mm (in) 0.07...0.16
(0.00276...0.0063)
0.07...0.16
(0.00276...0.0063)
Taper roller bearing preload mm (in) 0.05...0.1
(0.00197...0.03937)
0.05...0.1
(0.00197...0.03937)
Oil grades Brand-name hypoid gear oil, SAE 90 GL 5
Filling capacity Initial filling Initial filling
l (Imp. pints) 0.25 (0.44) 0.25 (0.44)
Oil changes Oil changes
l (Imp. pints) 0.23 (0.405) 0.23 (0.405)
Drive shaft
Layout Two-piece drive shaft with integral torsional vibra-
tion damper enclosed in single swinging arm
(BMW PARALEVER), universal joints at both
ends, sliding joint at rear wheel drive end.
Swinging arm
Swinging arm length mm (in) 355 (13.976) 355 (13.976)
Rear suspension
Suspension strut Suspension strut with
single-tube gas-filled
shock absorber, contin-
uously variable re-
bound-stage damping
and seven-position ad-
justable spring preload.
Suspension strut with
single-tube gas-filled
shock absorber, contin-
uously variable re-
bound-stage damping
and seven-position ad-
justable spring preload.
Suspension travel mm (in) 135 (5.315) 135 (5.315)
