46.4
Technical Data R 1100 RT
Location of manufacturer’s type plate / frame number On frame, at right
Length, overall mm (in) 2230 (87.795)
Max. height excl. mirrors mm (in) 1380 (54.33)
Width over handlebar, with weights mm (in) 775 (30.512)
Width over pillion footrests mm (in) 677 (26.65)
Height of seat at unladen weight mm (in) 800 (31.496)
- with adjustable seat mm (in) 780/800/820
(30.71/31.496/32.28)
Wheelbase in normal-load position mm (in) 1485 (58.4645)
Ground clearance in normal-load position mm (in) 153 (6.024)
Caster angle in normal-load position mm (in) 122 (4.803)
Steering head angle in normal-load position ° 62.9
Max. heel angle with 85 kg rider ° 46
Max.wheel track offset mm (in) 9 (0.354)
Unladen weight, ready for road, full tank kg (lb) 275 (606.375)
Axle load distribution (without rider),
front/rear % 51/49
Permitted total weight kg (lb) 490 (1080.45)
