Technical Data R 1100 RS
Engine, general
Engine design Four-stroke flat twin, air-cooled with oil-cooled
exhaust ports, installed longitudinally, 4 valves
per cylinder, two high-mounted camshafts, elec-
tronic fuel injection.
Location of engine number Crankcase
Cylinder bore mm (in) 99.0 (3.898)
Stroke mm (in) 70.5 (2.776)
Effective displacement cc 1085
Compression ratio 10.7 : 1
Power output kW(bhp)/min
-1
66(90)/7250
Max. torque Nm/min
-1
95/5500
Permissible maximum engine speed min
-1
7900
Permissible continuous engine speed min
-1
7600
Idle speed min
-1
1000
+150
Direction of rotation Clockwise, looking at
ignition system
Compression test pressure
good
normal
poor
bar (psi)
bar (psi)
bar (psi)
above 10 (145.04)
8.5...10
(123.28...145.04)
below 8.5(123.28)
Intake port dia./cylinder head mm (in) 44 (1.732)
Lubrication system
Theoretical volume in circulation at 6000 min
-1
Lubricating oil l (Imp. pints)
Cooling oil l (Imp. pints)
36 (63.36)
30 (52.8)
Oil filter Full-flow type
Pressure differential needed to open bypass
valve
bar (psi) 1.5 (21.756)
Oil pressure warning light comes on below bar (psi) 0.2...0.5 (2.9...7.25)
Pressure relief valve opens at bar (psi) 5.5 (79.77)
Operating pressure bar (psi) 3.5...6.0 (50.76...87.02)
Oil content
without filter change l (Imp. pints)
with filter change l (Imp. pints)
min/max l (Imp. pints)
3.50 (6.16)
3.75 (6.6)
0.50 (0.88)
Permissible oil consumption l/1000 km
Imp.pint/miles
1.0
(1.41/500)
Oil pump
Oil pump 2 Duocentric pumps
Housing depth mm (in)
mm (in)
12.02...12.05
(0.47322...0.47441)
10.02...10.05
(0.3945...0.3957)
Height of rotor mm (in)
mm (in)
11.95...11.98
(0.4705...0.4717)
9.95...9.98
(0.3917...0.3929)
Axial play mm (in) 0.04...0.1
(0.0016...0.0039)
Wear limit mm (in) 0.25 (0.0098)
